Slide Table
Slide table which is ejected out of the machine for loading and unloading of the component.
Servo Motor
The Servo Motor features a rated power of 2.9 kW, with a rated rotational speed of 2000 RPM and maximum speed of 4000 RPM. It provides a rated torque of 18.6 Nm and a peak torque of 46 Nm.
Servo Motor
The Servo Motor features a rated power of 2.9 kW, with a rated rotational speed of 2000 RPM and maximum speed of 4000 RPM. It provides a rated torque of 18.6 Nm and a peak torque of 46 Nm.
Machine Base
Machine base is the foundation casted in iron.
Spindle
The Spindle has a 7.5 kW power rating, operates at a high speed of 24,000 RPM, and is powered by a 380 V supply.It draws 14.5A of current and operates at a frequency of 800 Hz for precision applications.
Spindle
The Spindle has a 7.5 kW power rating, operates at a high speed of 24,000 RPM, and is powered by a 380 V supply. It draws 14.5A of current and operates at a frequency of 800 Hz for precision applications.
4 STATION 8 SPINDLE
Isometric View
| Specification | Details |
|---|---|
| Machine Model | InnoPeel 3000 |
| Peeling Speed | Up to 500 mm/s |
| Material Compatibility | Metal, Plastic, Wood |
| Spindle Motor Power | 7.5KW |
| Servo Motor Precision | ±0.01 mm |
| Control System | Advanced PLC with Touchscreen Interface |
| Dimensions | 1200 mm x 800 mm x 1500 mm |
| Weight | 8 tons |
| Power Supply | 380V, 50/60 Hz |
6 STATION 12 SPINDLE
Isometric View
| Specification | Details |
|---|---|
| Machine Model | InnoPeel 3000 |
| Peeling Speed | Up to 500 mm/s |
| Material Compatibility | Metal, Plastic, Wood |
| Spindle Motor Power | 7.5KW |
| Servo Motor Precision | ±0.01 mm |
| Control System | Advanced PLC with Touchscreen Interface |
| Dimensions | 1200 mm x 800 mm x 1500 mm |
| Weight | 8 tons |
| Power Supply | 380V, 50/60 Hz |
PEELING MACHINCE ELECTRICAL LOAD
| PART NAME | SPECIFICATION | MODEL NUMBER | LOAD | QTY. |
|---|---|---|---|---|
| A.C SERVO DRIVE WITH MOTOR | 3PH 380-440VAC, 50/60HZ, 22A, CONT. AC 1PH, 380 - 440VAC, 50/60HZ, 0.2A, OUTPUT AC 3PH, 0-440VAC, 0-400HZ, 15A | S08-SPD32E1-050 | 7.5KW | 06 NOS. |
| VARIABLE FREQUENCY DRIVE | 3PH, 0-480VAC, 17A, 14KVA, 7.5KW | VFD075CB43A-20 | 7.5KW | 08 NOS. |
| HYDRAULIC MOTOR WITH EXHAUST FAN | 2.2KW, 3.0HP, 3PHASE, 415VAC, 4.7AMP, 1450RPM | 2.2KW | 01 NOS. | |
| LUBRICATION MOTOR | 3 PHASE, 415VAC | 0.5KW | 01 NOS. | |
| AC | 1 PHASE 220VAC | 01 KW | 01 NOS. | |
| CHILLER | 1 PHASE 220VAC | 02 KW | 02 NOS. |
Experience InnoPeel in Action
See how precision, automation, and innovation redefine industrial peeling.
Peeling Process 5:29
Transforming challenges into seamless solutions—InnoPeel leads the way.
Peeling Process 5:29
Transforming challenges into seamless solutions—InnoPeel leads the way.
Peeling Process 5:29
Transforming challenges into seamless solutions—InnoPeel leads the way.
WALL MIXER FIXTURE
UNIVERSAL FIXTURE FOR WALL MIXER/SINK MIXER AND RELATED FAMILY HOLDING FIXTURE
FIXTURE FOR SINGLE LEVER WALL MIXER
UNIVERSAL FIXTURE FOR SINGLE LEVER BATH MIXER AND RELATED FAMILY HOLDING FIXTURE
SHORT SINGLE LEVER BASIN MIXER FIXTURE
Universal Fixture for Single Lever Basin Mixer and Related Family Holding Fixture
LONG SINGLE LEVER BASIN MIXER FIXTURE
Universal Fixture for Single Lever Basin Mixer and Related Family Holding Fixture
News and Events
Stay Updated with the Latest Happenings
February 19, 2025
Plumber Bathware boosts faucet production with Innopeel innovation
The ability of Plumber Bathware to produce faucets will rise by about 30 per cent as a result of this innovation.
Read More..
Aaditya Mechatronics LLP excels in customer-focused automation solutions, driven by expert engineers and advanced in-house production capabilities.
